From pv magazine USA
The rapid growth of artificial intelligence is leading to changes in data center electrical systems. Modern AI training clusters now require 50 kW to 100 kW per rack. Traditional AC-based power systems struggle to meet these demands.
According to a white paper by Enteligent, a California-based developer of DC-to-DC power electronics, these legacy architectures are reaching their physical and economic limits. For a typical 10 MW AI datacenter, an 800VDC architecture provides $5.8 million in initial capital expenditure savings, said the company.
The savings come from eliminating expensive uninterruptible power supply (UPS) systems and rack power distribution units (PDUs). Annual operational expenses also drop by approximately $711,000 due to improved energy efficiency and lower cooling requirements, said the whitepaper.
Join us on April 22 for the 3rd SunRise Arabia Clean Energy Conference in Riyadh. The event will spotlight how solar and energy storage solutions are driving sustainable and reliable infrastructure, with a particular focus on powering the country’s rapidly growing data center sector. In a typical solar-powered facility, energy is generated as DC, inverted to AC for distribution, and then rectified back to DC several times before reaching a server. Enteligent’s architecture utilizes an 800VDC backbone that allows solar arrays and battery storage to connect directly to the system. This direct-DC coupling eliminates two complete conversion stages, reducing energy losses by 8% to 10% compared to traditional AC-interfacing models, said the whitepaper. Efficiency is a core advantage of the high-voltage DC model. Traditional AC systems often see end-to-end efficiency drop as low as 78%. Enteligent’s 800VDC system achieves 94% to 95% efficiency by simplifying the power path. The double-digit improvement reduces the total electricity load and the heat generated by the system. For solar developers, this means more of the generated clean energy powers the computing hardware rather than being wasted as heat. The 800VDC design also solves bottlenecks caused by copper, said the whitepaper. High-density AI racks at 240VAC require massive copper cables and high currents of 400 amps or more. At 800 V DC, current is reduced by approximately 70%. A 100 kW load requires only 125 amps, allowing for smaller #2 AWG conductors instead of bulky 4/0 AWG cables. This reduces copper mass by 50% to 80% and significantly lowers installation labor costs. Reliability improves as the number of failure points decreases. Traditional server power supplies are prone to failure due to high thermal loads and complex switching components. Enteligent replaces these with shared, high-efficiency DC power shelves at the rack level. The modules are hot-swappable, avoiding abrupt shutdowns. “Hot-swappable” means you can fix the equipment while the power is still on. As AI clusters scale toward 200 kW per rack, high-voltage DC provides a scalable foundation that AC distribution cannot safely match, said Enteligent. Hyperscale operators are already moving toward direct-DC standards to meet sustainability goals and manage rising power costs. By integrating solar and storage directly into an 800 V DC backbone, data centers can function as stabilizing assets for the grid while maximizing the value of on-site renewable energy. This content is protected by copyright and may not be reused. If you want to cooperate with us and would like to reuse some of our content, please contact: editors@pv-magazine.com.
