Inverted perovskite solar cell with 22.1% efficiency via star-shaped polymer

Share

Scientists at the Northwestern Polytechnical University in China and the Swiss Federal Institute of Technology, Lausanne (EPFL) have fabricated an inverted perovskite solar cell based on a star-shaped polymer that they claim is able to improve charge transport and inhibit ion migration at the perovskite interface.

Presented in the paper Efficient and stable inverted perovskite solar cells with very high fill factors via incorporation of star-shaped polymer, recently published in ScienceAdvances, the cell has a “p-i-n” layout and is based on a perovskite material known as CsMAFA modified with a polymer called polyhedral oligomeric silsesquioxane-poly(trifluoroethyl methacrylate)-b-poly(methyl methacrylate) or, more generally, PPP polymer.

“On the PPP polymer branches, there are multiple chemical anchor sites including carbonyl (C═O) and CF3, which act as 3D skeleton templates to passivate defects at the grain boundaries (GBs) and interfacial surfaces, inhibit nonradiative recombination and charge-transport loss, and improve stabilities under moisture, thermal, and illumination stress,” the Chinese-Swiss group explained. CF3 is a donor material that is commonly used to improve the performance of organic solar cells.

The PPP-modified perovskite is described as a densely packed, high-quality film with an average grain size of 350nm, which compares to 260nm of the same perovskite without the new polymer. It also showed improved steady-state photoluminescence (SSPL), which the academics attributed to the PPP molecules that can mitigate the trap density and passivate grain boundaries and surface defects. The PPP polymer was also found to reduce nonradiative recombination, charge-transport losses, and ion migration.

Popular content

The solar cell achieved a maximum power conversion efficiency of 22.1% and a fill factor of 0.862, which the research group defined as astoundingly high. “Surface recombination is likely to be the dominant recombination mechanism in the PPP-modified device,” the researchers explained. “Thus, it appears feasible to further boost the fill factor close to its Shockley Queisser limit of 0.904 by passivating defects in interfaces.”

An encapsulated version of the device also showed good operational stability with almost no change in efficiency after 1,000 hours of maximum power point tracking under one-sun illumination at 45 degrees Celsius.
